Automatic Passenger Elevators

Shubh Aarambh Motion Technology with Power of Excellence.

Shubh Aarambh Motion Technology with Power of Excellence. Shubh Aarambh Passenger Elevators employ advanced technology in vertical transportation. It provides comfortable, elegant quick and safe mode for up and down people movement in high rises. It is an amazing blend of state-of-the-art elevator technology and aesthetic appeal. Shubh Aarambh puts great emphasis on safety and the need to maintain disruption free motion of passengers. Our elevators come in various passenger capacities, speed and an array of functional features and interior layout to choose from..

Optional Function

  • Voice Announcement (Any Language).
  • Car LCD Display with message.
  • Duplex Control.
  • Group supervision function.
  • VIP service (for Elevator group).
  • Closed loop system to monitor motor performance.
  • Detection of stuck hall.
  • Button to skip landing.
  • Advance detection of floor before landing.
  • Parking system.
  • Car cell cancellation system.
  • Automated monitoring system with potential free contact.
  • Hand rail in car.
  • Time & Temperature display.
  • Automatic Rescue Device (slow speed/high speed).
  • Full collective system.
  • ClTime & Temperature display.
  • Automatic Rescue Device. (Slow Speed / High Speed).
  • Full collective system.
  • Overload protection with display and buzzer.
  • In between landing call bypass on full load.
  • Intercom facility.
  • Lift out of order display.
  • Touch Screen.

Standard Function

  • Down collective control.
  • VVF drive.
  • Emergency light.
  • Self diagnosis of breakdown.
  • Automatic leveling with ground floor on power restoration.
  • Floor position and direction indicator in car and landing.
  • Final limit protection.
  • Attend operation for nonstop destination landing..
  • ClOverload protection with display and buzzer.
  • In between landing call bypass on full load.
  • Intercom facility.
  • Direction change function in attend mode.
  • Independent operation.
  • Emergency alarm.
  • Door open announcement system.
  • Home landing.
CIVIL DIMENSIONS FOR PASSENGER LIFT (AUTOMATIC CENTRE OPENING DOOR)
CAPACITY CAR INSIDE LIFT WELL ENTRANCE MACHINE ROOM SIZE PIT OVER HEAD
Pass. Load in Kg. Width Depth Width Depth Width Depth Width Depth Height
4 272 1100 700 1600 1250 700 2000 3100 3750 2500 1500 4250
5 340 1100 850 1600 1400 700 2000 3100 3900 2500 1500 4250
6 408 1100 1000 1600 1600 700 2000 3100 4100 2500 1500 4250
8 544 1300 1100 1800 1700 800 2000 3300 4200 2500 1500 4250
10 680 1350 1300 1900 1900 800 2000 3400 4400 2500 1500 4250
13 884 2000 1100 2500 1700 900 2000 4000 4200 2500 1500 4250
16 1088 2000 1300 2500 1900 1000 2000 4000 4400 2500 1500 4250
20 1360 2000 1500 2500 2100 1000 2000 4000 4600 2500 1500 4250
CIVIL DIMENSIONS FOR PASSENGER LIFT (AUTOMATIC TELESCOPIC OPENING)
4 272 950 800 1400 1400 700 2000 2900 3900 2500 1500 4250
5 340 1000 900 1450 1500 700 2000 2950 4000 2500 1500 4250
6 408 1000 1100 1450 1700 700 2000 2950 4200 2500 1500 4250
8 544 1100 1300 1550 1950 800 2000 3050 4450 2500 1500 4250
10 680 1200 1450 1700 2100 800 2000 3200 4600 2500 1500 4250
CIVIL DIMENSIONS FOR PASSENGER MRL LIFT (AUTOMATIC)
5 340 850 1100 1600 1500 700 2000 3100 4000 2500 1500 4250
6 408 1000 1100 1800 1500 700 2000 3300 4000 2500 1500 4250
8 544 1100 1300 1900 1750 800 2000 3400 4250 2500 1500 4250
10 680 1200 1450 2100 2000 800 2000 3600 4500 2500 1500 4250
